6 IN AIR-TIGHT, IC/NON-IC HOUSING

Manufacturer: Lithonia Lighting | Catalog # L7X R6 | Electrozad South Part # 69594
$17.01 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL
Recessed incandescent housings for 2x8 new construction. Approved for direct burial in insulation and all ceiling and wiring types.

Technical Information

Aperture Size
6 in
Applications
Hospitality,Residential,Retail
Lamp Type
Halogen,Incandescent,LED - Static
Material
Steel
Mounting Type
Recessed
Number of Lamps
1
Standard
CUL
Type
Downlight

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
784231091906
Color
Silver
Environment
Indoor
Environmental Conditions
Indoor
GTIN
00784231091906
Product Type
Downlight
Product UPC
78423109190
Shape
Round
Weight
3.239 lb

Dimensions

Height
6.875 in
Length
17 in
Warranty Length
1 yr
Width
13.875 in

Certifications & Compliance

Country of Origin
Mexico
Overview
  • 1-year limited warranty
  • Standard 120 volts used in most residential applications
  • Approved for direct burial in insulation
  • Aluminum housing with three remodel clips for installation in existing plaster, sheet rock or mechanical ceilings
  • Air-tight, galvanized steel pan with aluminum can and junction box with four built-in ROMEX® clamps and ground wire. Rated for 90°C
  • 120 volt only.
  • Does not include light source
  • Emergency battery back-up not included in this version
  • Dimensions: Dimensions: Height 6-7/8-3/8-in. x Width 7-7/8-in. x Full Width 13-7/8. x Length 6-7/8-in. x Full Length 15-in.
  • UL Listed, CSA certified to US and Canadian standards, Listed for damp locations
