CIRCUIT BREAKER, POWERPACT H, 15A, 3 POLE, 600VAC, 50KA, LUGS, THERMAL MAGNETIC, 80%

Manufacturer: Schneider | Square D | Catalog # HLL36015 | Electrozad South Part # 419460
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual CAD Drawing #1 CAD Drawing #2 CAD Drawing #3 G USERS MANUAL URL I INSTALL ASSEMBLY INSTRUCTIONS URL
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 15A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.

Technical Information

Amperage
15 A
Applications
Distribution
Control Type
Toggle
Frame
L
Interrupt Rating
125 kA 240 V AC 50/60 Hz UL 489;100 kA 480 V AC 50/60 Hz UL 489;50 kA 600 V AC 50/60 Hz UL 489;20 kA 250 V DC UL 489;50 kA 500 V DC UL 489
Line Rated Current
15-15 A
Mounting Type
Unit Mount Lug)
Net Weight
2.2 kg
Number of Poles
3
Operating Temperature
40 Adegrees C
Range
PowerPact
Standard
CSA,IEC 60947-2,NEMA,NOM-003-SCFI-2000,UL
Storage Temperature
-50-85 degrees C
Strip Length
16 mm
TC Connection
AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE
Trip Point
750-750 A
Trip Range
15 A,350 A,750 A
Trip Type
thermal-magnetic
Type
circuit breaker
Voltage
250 V

Manufacturer Information

Brand
Square D
Sub Brand
POWERPACT

General Product Info

12-Digit UPC
785901598879
Color
Black
GTIN
00785901598879
Product UPC
78590159887
Weight
2.2 kg

Dimensions

Depth
3.39 in
Height
6.42 in
Length
16 mm
Warranty Length
18 mth
Width
4.09 in

Certifications & Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CSA,NOM,UL
Country of Origin
Mexico
Overview
  • HLL36015 is a PowerPact H Circuit Breaker,ThermMagn,15A,3P,600V,50kA. This circuit breaker has a breaking capacity of 20kA@250 V DC with a continuous current rating of 80%.
