RETROBASICS DOWNLIGHT TRIM KIT, SWITCHAB

Manufacturer: Juno Lighting | Catalog # RB56S SWW5 MW M6 | Electrozad South Part # 387548
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL

Technical Information

Aperture Size
5 in
Applications
Hospitality,Offices & Banks,Residential,Retail,Retrofit
Average Rated Life
50,000 hr
Color Rendering Index
90 CRI
Color Temperature
2700 K
Lamp Life
50,000 hr
Lamp Type
LED - Dynamic
Lumens
850 lm
Material
Plastic
Mounting Type
Recessed
Standard
CSA
Type
Trim
Voltage
120 V
Wattage
7.2 W

Manufacturer Information

Brand
Juno Lighting

General Product Info

12-Digit UPC
196182750144
Color
White
Construction
Retrofit
Environment
Indoor
Environmental Conditions
Indoor
Finish
Matte
GTIN
00196182750144
Product Type
Trim
Product UPC
19618275014
Shape
Round
Weight
0.44 lb

Dimensions

Height
2.11 in
Length
7.68 in
Warranty Length
5 yr
Width
7.68 in

Certifications & Compliance

Country of Origin
China,China
Overview
  • WARRANTY: 5-year limited warranty
  • INSTALLATION: All-in-one design with integrated electronics into trim, replacing the existing lamp & trim; features a quick connect plug for easy electrical connection from housing to trim module; pre-installed torsion springs; E26 socket adaptor included
  • SWITCHABLE WHITE: Features Switchable White Technology with a tactile slider switch integrated into the trim allowing for easy color adjustments between 5 color temperature options (2700K, 3000K, 3500K, 4000K, or 5000K)
  • CONTROLS: Dimmable, flicker-free dimming, from 100% to 10%
  • DESIGN: Designed for easy, simple installation fitting most 5\" or 6\" compatible recessed housings
  • ENERGY SAVINGS: Energy efficient LED luminaires maximize energy savings
  • HOURS OF LIFE: Long life energy efficient LED, rated for 50,000 hours at 70% lumen maintenance
  • IC RATED: For use with housings installed in direct contact with insulation
  • DIMENSIONS: Lens Width 4.95in, Trim Width 7.62in, Product Height 2.16in
  • LISTINGS: CSA certified for sale in the USA and Canada; Suitable for wet location; Air-Loc certified in accordance with ASTM E283-2004
