LED WALL PACK, LED, 5000K , 120-277V, DA

Manufacturer: Lithonia Lighting | Catalog # WPX3 LED 50K MVOLT DDBXD M2 | Electrozad South Part # 381461
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL
LED Economical Round Bay Light, 18,000 nominal lumens, Glass lens, 347V-480V, 4000K, 80 color rendering index, White, super durable

Technical Information

Applications
Automotive & Parking,Closet,Education,Government,House Of Worship,Manufacturing,Offices & Banks,Parking Garage,Retail,Sports And Recreation,Transportation,Utility,Warehouses
Color Rendering Index
70 CRI
Color Temperature
5000 K
Lamp Type
LED - Static
Lumens
9200 LM LM
Material
Aluminum
Mounting Type
Surface
Power Source
Hardwired
Size
9.5x13x5.5
Style
Traditional
Type
Wallpack
Voltage
120 V
Wattage
69 Watt

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
193048870824
Color
Bronze
Environmental Conditions
Outdoor
Finish
Gloss
GTIN
00193048870824
Product UPC
19304887082
Weight
11 lb

Dimensions

Height
5.5 in
Length
9.5 in
Width
13 in
Overview
  • Five-year limited warranty
  • MVOLT driver operates on any line voltage from 120-277V (50/60Hz) and can be mounted directly over a standard electrical junction box, or using conduit ports on the sides or back where wiring can be made in the integral wiring compartment in all cases
  • Die-cast aluminum main body with optimal thermal management that both enhances LED efficacy and extends component life and the luminaires are IP66 rated and sealed against moisture and environmental contaminants
  • Hardwired on/off capability only
  • The WPX LED wall packs are energy-efficient, cost effective, and aesthetically appealing solutions for both HID wall pack replacement and new construction opportunities
  • 9,200 lumen output and 69W
  • Light engine(s) configurations consist of high-efficacy LEDs and LED lumen maintenance is L90/100,000 hours
  • Geometric shape covers the footprint of a typical HID wall pack, covering any unsightly stains.
  • 13.0 in x 9.5 in x 5.5 in
  • CSA certified to meet US and Canadian standards, suitable for wet locations, IP66 Rated and DesignLights Consortium® (DLC) Premium qualified product
