StrongHold™ EV10-10RB-Q Ring Terminal, Yellow, Vinyl, 1/5" Stud, 12-10 AWG,

Manufacturer: Panduit | Catalog # EV10-10RB-Q | Electrozad South Part # 377840
$38.59 /c (100 ea)
ea
Order in multiples of 25 (pack qty)
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL
StrongHold EV10-10RB-Q Contractor Grade Vinyl Insulated Ring Terminals are a reliable and economical option that withstand a wide range of general-purpose applications. Accommodates 12-10 AWG wire gauge, compatible with #10 Stud, are yellow in color, and come in packages of 25.

Technical Information

Barrel Length
0.45 in
Barrel Type
Funnel
Color Coding
Yellow
Material
Copper
Max Operating Temperature
105 degrees C
Minimum Operating Temperature
105 degrees C
Size
#10
Tongue Thickness
0.04 in
Tongue Width
0.31 in
Type
Ring Terminal
Wire Size
#10

Packaging

Package Qty
25

Manufacturer Information

Brand
Panduit
Sub Brand
StrongHold™

General Product Info

12-Digit UPC
074983281855
Color
Yellow
Finish
Tin-Plated
GTIN
00074983281855
Product UPC
07498328185

Dimensions

Outer Diameter
0.31 in
Overall Length
1.05 in
Width
0.31 in

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
Mexico
