S200UDC MCB 1P K 6A 60VDC BCPD

Manufacturer: ABB Inc | Catalog # S201UDC-K6 | Electrozad South Part # 373902
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Brochure
Miniature Circuit Breaker, Supplementary Protector, Rated Current 6 Amps, 1 Pole, Interrupt Rating 14 kA, Trip Curve K, Electromechanic Tripping Mechanism for Short Circuit Protection, Voltage up to 60/125 VDC, DIN Rail Mounted, Finger Safe and Multi-Function Terminals, UL 489, CSA 22.2 No. 5

Technical Information

Amperage
6 A
Applications
Designed for Allowing Higher In-Rush Current During System Start Up; Example: Motors, Transformers
Frequency
50/60 Hz
Interrupt Rating
14 kA
Number of Poles
1
Operating Temperature
-25 To 55 degrees C
Standard
UL 489
Trip Type
K
Type
High Performance MCB Provides Compact Supplementary, Energy Limiting, Circuit Protection
Voltage
60/125 V

Manufacturer Information

Brand
ABB

General Product Info

12-Digit UPC
804325569705
Box Quantity
10
GTIN
04016779825993
Product UPC
80432556970

Dimensions

Height
92 mm
Length
71 mm
Width
17.5 mm
