Pan-Lug™ LCMA16-6-C Comp. Lug, Metric, 16mm, Tin Plt Copper, Strt, One #10 Stud

Manufacturer: Panduit | Catalog # LCMA16-6-C | Electrozad South Part # 337688
$247.88 /c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL
The LCMA16-6-C Tin-Plated Copper Compression Metric Lug, one-hole, standard barrel, has a rounded tongue convenient for use in tight spaces and a beveled wire entry for fast and easy installation. The inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified.

Technical Information

Angle
Straight
Barrel Length
14.5 mm
Barrel Type
Standard Barrel Length With Inspection Window
Cable Size
AWG
Material
Copper
Number of Holes
NA
Stud Size
0.2362 in
Tongue Thickness
1.1 mm
Tongue Type
Round
Tongue Width
13 mm
Type
Metric Compression Lug

Packaging

Package Qty
100

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Lug™

General Product Info

12-Digit UPC
074983769339
GTIN
00074983769339
Product UPC
07498376933

Dimensions

Outer Diameter
0.28 in
Overall Length
34.3 mm

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
AR
