OUTDOOR LED FLOODLIGHTS, LED, 4000K, 120

Manufacturer: Lithonia Lighting | Catalog # TFX2 LED 40K MVOLT IS DDBXD | Electrozad South Part # 336380
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL
The TFX2 delivers 13,200 lumens and can replace up to 250W metal halide. The TFX LED floodlight family is an industry-leading distributor stock solution providing cost-effective and energy-efficient solutions to replace HID floodlights. In addition, payback can be achieved in less than two years, due to DLC Premium listing and 140 lumens per watt efficacy. For the full solution, the TFX comes in four sizes delivering 7,000 to 41,000 lumens replacing 70W to 400W metal halide luminaires.

Technical Information

Average Rated Life
100,000 hr
Color Rendering Index
70 CRI
Color Temperature
4000 K
Lamp Type
LED - Static
Lens Material
Glass
Lumens
13, 200 lm
Material
Aluminum
Mounting Type
Tenon Slipfitter
Power Source
Hardwired
Size
4.75x14.875x17.750
Standard
UL Listed
Style
Traditional
Type
Floodlight
Voltage
120 V
Wattage
94 W

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
193047670241
Color
Bronze
Environment
Outdoor
Environmental Conditions
Outdoor
Finish
Gloss
Fixture Type
Floodlight
GTIN
00193047670241
Product Type
Floodlight
Product UPC
93047670241
Shape
Rectangular
Weight
13.58 lb

Dimensions

Height
17.75 in
Length
4.75 in
Width
14.875 in

Certifications & Compliance

Country of Origin
China
Overview
  • Five-year limited warranty
  • 120V-277V and the integral slipfitter option mates with standard 2-3/8 inch tenons for pole-top mounting and is suitable for aiming in any orientation while being tilted from 0° horizontal facing downwards up to 180° horizontal facing upwards
  • Die-cast aluminum main body with optimal thermal management that both enhances LED efficacy and extends component life where the light engines andhousing are IP66 rated and sealed against moisture or environmental contaminants
  • Hardwired on/off capability only
  • The TFX LED flood luminaire is a cost-effective, energy-efficient and long-life solution for replacing metal halide or HPS floodlights
  • Replace up to 250W metal halide while saving 68% in energy costs
  • Light engine(s) configurations consist of high-efficacy LEDs and LED lumen maintenance is L90/100,00 hours
  • No emergency battery back-up available in this version
  • 14-7/8 in x17-3/4 in x 4-3/4 in
  • UL Certified to meet US and Canadian standards, suitable for wet locations, IP66 rated, DesignLights Consortium® (DLC) Premium qualified product
