CNY, LED, PACKAGE 1, 5000K , 120-277V, D

Manufacturer: Lithonia Lighting | Catalog # CNY LED P1 50K MVOLT DDB M4 | Electrozad South Part # 327125
$167.62 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 5 to 7 days
Specification Sheet Product Brochure Installation / Instruction Manual I INSTALL ASSEMBLY INSTRUCTIONS URL
The CNY LED canopy luminaires are energy efficient and budget friendly, perfect for replacing up to 400W metal halide luminaires while saving up to 80% energy costs. Quick mount mechanism significantly reduces the installation time. An LED array and translucent lens create uniform and visually comfortable illumination. CNY LED luminaires are DLC Premium listed and deliver quick payback!

Technical Information

Aperture Size
10 in
Applications
Offices & Banks,Retail
Color Rendering Index
70 CRI
Color Temperature
5000 K
Lamp Type
LED - Static
Lens Color
Clear
Lens Material
Polycarbonate
Lumens
8500 lm
Material
Aluminum
Mounting Type
Surface
Number of Lamps
1
Standard
C-UL-USDLC Premium
Style
Traditional
Type
Canopy
Voltage
120 V

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
191848093337
Color
Bronze
Environmental Conditions
Outdoor
Finish
Gloss
GTIN
00191848093337
Product Type
Canopy
Product UPC
91848093337
Shape
Square
Weight
6.5 lb

Dimensions

Height
4.125 in
Length
10.25 in
Warranty Length
5 yr
Width
10.25 in

Certifications & Compliance

Country of Origin
China
Overview
  • Five-year limited warranty
  • Quick mount mechanism significantly reduces installation time with no need to open the luminaire for installation and can mount to recessed junction box, surface mount with three conduit entry points or pendant mounted with ¾ NPT pendant stem
  • Cast-aluminum, corrosion-resistant housing with polyester powder paint for lasting durability where castings sealed with a one-piece gasket and frosted lens is designed for uniform light distribution
  • Hardwired on/off capability only
  • The quick mount mechanism of the CNY significantly reduces installation time
  • Energy efficient and budget friendly, perfect for replacing up to 400W metal halide luminaires while saving up to 80% energy costs
  • LEDs maintain 70% of light output at 50,000 or more hours of service life (L70/50,000 hours)
  • No emergency battery back-up available in this version
  • 10 in x 4.5 inch x 10 inch
  • UL Certified to US and Canadian safety standards and wet location and listed DesignLights Consortium® (DLC) qualified product and can be used to comply with California Title 24 Part 6 High Efficacy LED light Source Requirements
