SP TOG, IND GRD, 20A 120/277V, LK, IV

Manufacturer: Hubbell Wiring Devices | Catalog # HBL1221LI | Electrozad South Part # 315343
*Call For Price*
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Specification Sheet Product Catalog Page Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL P WARRANTY URL
Switches and Lighting Controls,Extra Heavy Duty Industrial Grade, Locking Toggle Switches, General Purpose AC, Single Pole, 20A 120/277V AC, Back and Side Wired, Ivory Key Guide

Technical Information

Action
Snap
Actuator
Double Ended Key
Amperage
20 A
Applications
Back and Side Wired
Base Material
Thermoset
Contact Configuration
2-Position
Contact Material
Silver Alloy
Contact Rating
Full Rated
Current
20 A
Enclosure
None
Flamability Class
UL 94V-2
Grade
Industrial
Indicator
Dot Indicates On
Lock Type
Non-Cylindrical
Material
Thermoset,Thermoset
Max Current
20 A
Max Voltage
277 V
Number of Poles
1
Operating Temperature
-40 degrees C
Screw Material
Brass
Size
4.06 in x 1.31 in x 1.13 in
Style
Single Pole
TC Connection
Terminal Screws
Temperature Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Type
Locking
Voltage
120-277 V
Wattage
5,540 Watt
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell
Sub Brand
AC Toggle Switches

General Product Info

12-Digit UPC
783585188560
Color
Ivory
GTIN
00783585188560
Product Series
Extra Heavy Duty
Product UPC
78358518856

Dimensions

Height
1.13 in
Length
4.06 in
Width
1.31 in

Certifications & Compliance

Country of Origin
China
Overview
  • Strip gauge for accurate wiring
  • Large brass binding head screws with deep slots
  • Lock circuits On or Off
