Splicer/reducer type-SR aluminium 250KCMIL-6AWG

Manufacturer: Panduit | Catalog # SR-250-XY | Electrozad South Part # 18107
$4,322.36 /c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 12 to 18 days
Product Catalog Page Installation / Instruction Manual D BRAND LOGO IMAGE URL H TECHNICAL DRAWING URL I INSTALL ASSEMBLY INSTRUCTIONS URL
Splicer/reducer for use with stranded aluminium or copper code conductors. Made from high strength extruded aluminium alloy to provide premium electrical and mechanical performance. Tin-plated to inhibit corrosion. Rounded bottoms to facilitate taping. Solid center barrier prevents contact of dissimilar metal conductors. Wide wire range-taking capability minimizes inventory requirements.

Technical Information

Base Material
Aluminum
Conductor Size
250 kcmil Code - #6 AWG Code
Material
Aluminum
Type
Mechanical Splicer/Reducer

Packaging

Package Qty
10

Manufacturer Information

Brand
Panduit
Sub Brand
Pan-Lug™

General Product Info

12-Digit UPC
074983607709
Finish
Tin Plated
GTIN
00074983607709
Product UPC
07498360770
UNSPSC
39121458

Dimensions

Height
1.13 in
Length
3.94 IN
Overall Length
3.94 in
Width
1 in

Certifications & Compliance

BAA | Buy American Compliant
Y
Country of Origin
Mexico
